| RF Frequency | 10.7 to 12.75 GHz |
| IF Frequency | 2750 to 4750 MHz |
| Reference Frequency | 10MHz，0dBm±5dBm |
| Saturated Output Power | 40 dBm min. |
| Rated Output Power | 40 dBm |
| Linear Output Power | 37 dBm |
| Third Order Intermodulation | -25 dBc max. |
| Small Signal Gain | 65 dB |
| Gain Variation(Fixed Frequency) | 3 dB p-p max. |
| Gain Variation(Fixed temperature) | 1 dB p-p max. over 36 MHz, 3 dB p-p max. over 500 MHz 4 dB p-p max. over 750 MHz |
| Gain Adjustment Range | 20 dB, 0.5 dB Step |
| Phase Noise | -65 dBc/Hz max. @100 Hz -75 dBc/Hz max. @1 KHz -85 dBc/Hz max. @10 KHz -95 dBc/Hz max. @100 KHz |
| Output Spurious | -60 dBc max. |
| Output VSWR | 1.25：1 |
| Input VSWR | 1.5：1 |
| Weight | 1.1kg |
| Size（L×W×H） | 5.51”×3.62”×2.74‘’（140mm×92mm×69.5mm） |
| Operating Temperature | -40℉ to 140℉（-40℃ to +60℃） |
| Humidity | 0% to 100% |
| Altitude | 0 to 9842ft |
