The SATCOM series 2000W Ku-Band SSPA supports enable amplify the power of the RF signal. It provides superior performance,
which meets the demand of satellite earth base station system, as an important part of the uplink of microwave channel equipment for
the satellite communications. The 2000W Ku-Band SSPA consists of RF unit, power supply unit and Monitoring & Controlling unit, with
the functions of protection, signal monitoring and self-checking.
SSPA Interfaces & Power Supply
| F Input Connector： | SMA-K |
| RF Output Connector： | WR75 |
| Power Supply Connector： | YGD20S2204J |
| M&C Connector： | YW122E01,Support Ethernet |
| RF Sampling Connector: | SMA-K |
| Power Supply： | 323 to 437VAC，47 to 63Hz |
| Power Supply Draw @ PRated： | 11000W（typ.） |
| LED Indicators: | Green LED on : Functioning properly, Red LED flashing: Alarm |
RF Specifications
| RF Frequency | 13.75 to 14.5 GHz |
| Saturated Output Power | 63 dBm min. |
| Rated Output Power | 63 dBm |
| Linear Output Power | 60 dBm |
| Third Order Intermodulation | -24 dBc max. |
| Small Signal Gain | 75 dB |
| Gain Variation (Fixed temperature) | 0.5 dB p-p max. over 54 MHz
2 dB p-p max. over 750 MHz |
| Gain Adjustment Range | 30 dB, 0.1 dB Step |
| Output Spurious | -70 dBc max. |
| Input VSWR | 1.3：1 |
Physical
| Weight | 60kg |
| Size（L×W×H） | 24.15‘’×14.478‘’×11.979‘’（805mm×482.6mm×399.3mm） |
| Operating Temperature | 14℉ to 122℉（-10℃ to +50℃） |
| Humidity | 0% to 100% |
| Altitude | 0 to 9842ft |
